YB220 series AC single-phase general purpose filter
Short Description:
YB220 series single-phase universal filter (This series of products can provide terminal station wiring) Rated voltage: 250VAC Rated current: 6 ~ 100A Optional Lead, solder, bolt, terminal station and other connection methods are available Customized products are available
YB220 series single-phase universal filter
Rated voltage: 250VAC
Rated current: 6 ~ 100A Optional
Lead, solder, bolt, terminal station and other connection methods are available
Customized products are available
Characteristics and advantages
– Ordinary AC filter, with better filtering effect,
The effective filter range is 5KHz-30MHz
– Compact structure, cost-effective, safe and convenient, more reliable
– 380VAC (inclusive) and above high working voltage products are optional
Application field
Electronic and electrical equipment, consumer electronics, household appliances, medical equipment, data communication equipment, office automation
Chemical equipment
